SKYRS Pakistan – Product Data Sheet
OPR-NH401PHU
1U Rack-Mounted 16-Channel H.265 HDMI IP Streaming Encoder
The OPR-NH401PHU is an ultra-dense, enterprise-grade 1U rack-mounted video encoding appliance designed for high-capacity IPTV deployments, corporate AV distribution, educational networks, and digital signage matrices across Pakistan. By packing 16 independent HDMI channels into a compact 1U form factor, it delivers exceptional space efficiency alongside advanced H.265 (HEVC) compression to optimize high-definition streaming over modern network infrastructures.
Key Features and Capabilities
-
Ultra-Dense 1U Profile: Houses 16 independent HDMI input channels within a single rack unit, dramatically reducing server room footprint and power overhead.
-
Advanced H.265 / HEVC Compression: Cuts bandwidth consumption by up to 50% compared to traditional H.264 encoders, enabling smooth HD streaming across Pakistan’s varied regional network conditions.
-
Broad Stream Protocol Engine: Seamlessly supports SRT, RTMP, RTSP, HTTP, HLS, UDP, RTP, Multicast, and Unicast for direct pairing with local IPTV headends or global CDN networks.
-
Multi-Stream Per Channel: Each HDMI input generates a primary and secondary stream, allowing independent bitrate and resolution tuning for simultaneous local archiving and remote internet broadcasting.
-
High-Fidelity Audio: Supports embedded HDMI audio encoding with customizable AAC, MP3, and G.711 compression formats.
Product Variants Available for SKYRS Pakistan
SKYRS offers localized variations of the OPR-NH401PHU configured for the specific infrastructure, power, and environmental demands of major Pakistani municipalities:
Technical Specifications
-
Video Input: 16 x HDMI 1.4 (Type A Interface)
-
Maximum Encoding Resolution: 1080p @ 60fps per channel
-
Video Coding: H.265 / HEVC Main Profile; H.264 / AVC Baseline, Main, and High Profiles
-
Bitrate Range: 16Kbps to 12Mbps per channel (CBR / VBR selectable)
-
Network Interface: 1000M RJ45 Full-Duplex Adaptive Ethernet Ports
-
System Management: Password-protected, web-based GUI allowing secure remote login, batch configurations, and over-the-network firmware updates.
SKYRS Support & Integration Note: All OPR-NH401PHU variants sold in Pakistan include a 1-year local warranty. Onboard software includes optimized network parameters verified for stable streaming across prominent national broadband networks, including PTCL, Nayatel, StormFiber, and Transworld.
