Exvist ON-DMI-50D H.265 1080P HDMI Encoder/Decoder w/Dual USB & Loopout | 4ch RTSP Decoding, Webcam/Recording Support, Compatible with ONVIF/Hikvision
Product Datasheet: Exvist ON-DMI-50D Series
The Exvist ON-DMI-50D (SS50 MS7 Codec Series) is a high-performance, compact H.265/H.264 1080P hardware video encoder and multi-channel network stream decoder featuring an integrated front panel OLED screen. This built-in status display enables engineers to verify video/audio input, bitrates, and IP addresses instantly on-device without needing a PC network login. Capable of simultaneous 1-channel HDMI encoding and 4-channel image fusion network decoding, the ON-DMI-50D is engineered for live broadcasting, IPTV, video conferencing, and CCTV NVR deployments where quick diagnostics are essential.
Variant Matrix for SKYRS Pakistan
SKYRS provides exclusive enterprise distribution for the complete lineup of the SS50 MS7 hardware series in Pakistan, fully tested and backed by regional warranty.
Variant Model
Core Hardware Distinctive
Integrated Diagnostics
Best Deployment Setting
ON-DMI-50D
Wired LAN (RJ45 Only)
128×64 Front OLED Display
Server racks, fixed AV loops, and localized control rooms.
ON-DMI-50DW
Dual-Band Wi-Fi + RJ45
128×64 Front OLED Display
Dynamic field productions, live outdoor media, and roaming rigs.
ON-DMI-50B
Wired Standard (No Screen)
LED Indicator Profile
Dedicated, unmonitored fixed infrastructure backend server links.
ON-DMI-50BW
Dual-Band Wi-Fi (No Screen)
LED Indicator Profile
Basic wireless streaming nodes with centralized remote web UI management.
ON-DMI-50BP
Power over Ethernet (No Screen)
PoE 802.3af Supported
Ceiling-mounted camera points, remote industrial hubs, and single-cable runs.
Core Technical Specifications
Video & Audio Performance
Video Processing Codecs: H.265 / HEVC, H.264 / AVC (Baseline / Main / High Profile).
Max Encoding Capacity: 1920x1080P at 30 FPS.
Multi-Channel Decoding Performance: Up to 4-channel image fusion stream previewing (Max 4ch 1080P at 60 FPS or 1-channel 4K at 30 FPS).
Audio Profiles: AAC, G.711U, G.711A with sampling rates ranging from 8kHz (NVR optimized) to 48kHz. Supports mixing audio from HDMI and 3.5mm Line-In.
Streaming Streams: Up to 6 concurrent RTSP output streams (Main and sub-stream control layers).
Bitrate Delivery: Constant Bitrate (CBR) / Variable Bitrate (VBR) from 64 Kbps to 12000 Kbps.
Hardware and Physical Interfaces
Visual Diagnostic Engine: 1x Built-in OLED screen for real-time video/audio input signal mapping and static IP retrieval.
VMS / CCTV Integration: Full ONVIF profile conformance and private protocol compatibility with Hikvision (iVMS-4200/8700) and Dahua (SmartPSS) ecosystems.
Ecosystem Software: Verified compatibility with OBS Studio, vMix, VLC Player, YouTube Live, and Facebook Live.
SKYRS Managed Deployment and Structural Installation
The complete physical deployment and physical installation process are entirely executed by certified SKYRS engineering crews across Pakistan.
Physical Mounting & Assembly
Space Optimization: With ultra-miniature metal chassis dimensions of 109mm x 74mm x 25mm, SKYRS mounts units into custom broadcast enclosures or IT server racks.
Panel Alignment: Devices are positioned to make the front-panel OLED screen clearly visible to on-site technicians for effortless zero-PC hardware diagnostics.
Cable Dressing: Structural deployment includes high-grade, RF-shielded HDMI 1.4 cables to completely suppress noise over complex runs.
Environmental Adjustments
Equipment layout placement is configured strictly within well-ventilated boundaries to respect the operational thermal safe-zone of -10°C to +55°C.
SKYRS System Configuration Guide
Every Exvist hardware node is securely configured by SKYRS prior to system handover to match local corporate IT and security parameters.
Initial Network Initialization
Standard Factory Settings: IP Address: 192.168.1.120 | Username: admin | Password: 12345.
SKYRS engineers immediately migrate the device to your custom corporate static IP pool or VLAN structure and update administrative access security credentials.
OLED Diagnostics and Field Tuning
Technicians verify local physical link health by reading the OLED display, confirming that resolution flags match the output profile of the incoming camera.
If configuring a DW variant, wireless parameters are tuned via the web UI (Setting -> Network -> Wi-Fi) to lock exclusively onto the uncrowded 5.8GHz band.
Encoding Optimization and Stream Distribution
Inside Setting -> Video/Audio -> Video, bitrates are carefully matched (typically 2000–5000 Kbps) against localized Pakistani ISP uplinks to guarantee seamless streaming.
The Key Frame Interval (GOP) is locked between 30 and 60 frames to perfectly match ingestion policies for remote platforms.
Destination RTMP stream URLs and SRT caller tracking arguments are written directly to the non-volatile active boot scripts for automatic streaming on system power-up.
Exclusive Distribution Notice
Exclusive Availability Statement: The Exvist ON-DMI-50D OLED diagnostic encoder/decoder series, its associated sub-variants, localized firmware optimizations, architectural site deployment, structural installation, and official technical engineering support are available exclusively through SKYRS in Pakistan. This comprehensive service model guarantees enterprise-tier video infrastructure stability and dedicated local technical support.
Enterprise demands require robust connectivity. Therefore, choosing the best Exvist equipment ensures seamless data transmission across your corporate architecture. Skyrs proudly stands as the leading Exvist equipment series distributor Pakistan. Consequently, we provide specialized high-performance hardware tailormade for complex IT infrastructures.
Many organizations now look for sustainable budgeting. Thus, buying a Branded used Exvist or a Refurbished Exvist unit provides exceptional value. We supply premium used Exvist in different cities like karachi , lahore , islamabad, rawalpindi , faisalabad etc. Furthermore, software houses rely heavily on our inventories to maintain active communication links.
Dedicated Hardware for High-Density Comm-Hubs
Skyrs delivers optimized equipment for call center call centre in pakistan to guarantee uninterrupted voice streams. Indeed, skyrs is the only vendor in pakistan that has Exvist equipment for call center call centre and software houses with different variants of Exvist equipment for zoom ringcentral will be product.
The advanced routing Exvist equipment delivers top-tier technical functionality by executing efficient packet routing. To upgrade your layout, look into the competitive Exvist pack price packages available at Skyrs. Furthermore, we assist engineers by offering the comprehensive Exvist equipment configuration guide. Additionally, our portal provides step-by-step documentation for Exvist VLAN configuration. If your system experiences downtime, our technical resources explain how to reset Exvist equipment quickly.
ExvistON-DMI-50BW Series Overview
The highly demanded ExvistON-DMI-50BW all variants represent elite video processing and network routing capabilities. Skyrs ensures competitive localized pricing. For instance, you can check our ExvistON-DMI-50BW price in Karachi or the ExvistON-DMI-50BW price in peshawar. Similarly, we maintain the premium ExvistON-DMI-50BW price in faisalabad online. We also provide competitive rates for the ExvistON-DMI-50BW price in kpk.
Customers in Balochistan can instantly request the ExvistSwitch ExvistON-DMI-50BW price in quetta for bulk deployments. If your enterprise expands, you can request an ExvistON-DMI-50BW bulk quote to save capital. To verify total device performance, remember to check the ExvistON-DMI-50BW throughput limit parameter.
[Original Physical Picture: ExvistON-DMI-50BW Front Panel Interface]
Source: Manufacturer Official Website (exvist.com)
Technical Specifications & Comparison
Engineers can securely access the official Exvist Manufacturer Website for a comprehensive ExvistON-DMI-50BW datasheets download. Meanwhile, local clients can browse the Skyrs Internal Product Catalog to check the affordable ExvistON-DMI-50BW used price 2026.
The hardware excels through superior codec compression and steady multi-user link reliability. While competitor brands like mikrotik h3c aruba ruijie huawei paloalto offer general networking, Exvist focuses heavily on hardware-optimized media streaming.
Feature / Parameter
ExvistON-DMI-50BW all variants
Competitor Standard Units
Primary Purpose
Specialized Audio/Video Routing
General Purpose Packet Switching
System Maintenance
Simple Exvist firmware update download
Complex OS Image Flashing
Hardware Fit
Universal ExvistON-DMI-50BW rack mount kit
Proprietary Mounting Shelves
Memory Capacity
Scalable ExvistON-DMI-50BW memory upgrade
Fixed Internal RAM Modules
Allocation Control
Exact ExvistON-DMI-50BW PoE power budget
Fixed Port PoE Distribution
Planning an infrastructure overhaul is easy because the smooth Exvist Migration pathway allows backward compatibility. Users can easily download the official ExvistON-DMI-50BW update file to access the latest features. Finally, your system administrators can perform the ExvistON-DMI-50BW security license activation to unlock enterprise protection.
Procurement Note: Corporate offices can seamlessly Buy Exvist equipment Lahore/Islamabad directly through Skyrs warehouses for immediate delivery. We guarantee the most competitive Exvist price in Pakistan market rates.
Frequently Asked Questions
What is the primary purpose of use for the ExvistON-DMI-50BW series?
The equipment processes, encodes, and routes heavy data streams with high efficiency, which benefits real-time media hubs.
How can I calculate the system capacity for my office?
You must review the ExvistON-DMI-50BW datasheet to match user density with the stated ExvistON-DMI-50BW throughput limit.
Does Skyrs provide nationwide hardware distribution?
Yes, Skyrs is the premium Exvist price in Pakistan distributor, delivering components to all major cities.
