DATA SHEET: CH701 ADVANCED TRANSCEIVER SERIES
The CH701 is a ruggedized, industrial-grade signal processing and transceiver unit designed for high-reliability data transmission, signal conversion, and communication interfacing. Built to withstand demanding environmental conditions, the CH701 ensures uninterrupted data flow and seamless system integration for enterprise, industrial networking, and defense applications.
PRODUCT VARIANTS (PAKISTAN SPECIFICATION)
To meet the diverse infrastructure demands across various sectors in Pakistan, the CH701 series is supplied in three distinct engineering variants:
CH701-S (Standard Enterprise): Optimized for standard indoor rack deployments, offering high-speed Ethernet-to-fiber signal conversion and local network bridging.
CH701-I (Industrial Hardened): Featuring an IP30-rated aluminum enclosure, extended temperature tolerance (-40°C to 75°C), and enhanced surge protection. Ideal for manufacturing plants, oil and gas setups, and outdoor enclosures in high-temperature regions of Pakistan.
CH701-W (Wireless/RF Integrated): Equips the core architecture with dual-band wireless bridging and RF transceiver capabilities, designed for remote telemetry and hard-to-wire commercial environments.
TECHNICAL SPECIFICATIONS
Data Interfaces: Multi-port RJ45 (10/100/1000 Base-T) and SFP Slot (1000 Base-X)
Operating Voltage: 12-48V DC redundant terminal blocks or 220V AC adapter options
Power Consumption: Less than 8 Watts at peak load
Isolation Protection: 4KV ESD and surge protection on all physical data ports
Form Factor: Compact DIN-rail mountable or wall-mount design
DEPLOYMENT & INSTALLATION
Pre-Installation Requirements Ensure the power source matches the specific voltage input of your CH701 variant. Verify that environmental conditions (humidity and temperature) match the tolerance ratings of the deployed unit. Ensure all data cables (Cat6 STP or Single-Mode/Multi-Mode Fiber) are certified and tested.
Physical Mounting
For Industrial (CH701-I) variants: Snap the integrated rear clip onto a standard 35mm DIN rail inside the control panel or enclosure.
For Standard (CH701-S) variants: Secure the chassis onto a flat wall surface or standard AV/IT rack shelf using the included side-mounting ears and screws.
Hardware Interconnection
Connect the incoming field data line (e.g., fiber backbone) to the SFP transceivers inserted into the CH701 optical port.
Connect the local network equipment or endpoint device to the RJ45 Ethernet ports using shielded twisted pair (STP) cables to ground ambient noise.
If using the CH701-W variant, securely screw the high-gain omnidirectional antennas onto the SMA coaxial connectors on the top panel.
Power Up Sequence Attach the grounding wire to the chassis ground screw to prevent static damage. Connect the power lines to the DC terminal block or plug in the AC adapter. Power on the main circuit breaker.
CONFIGURATION
The CH701 utilizes an intuitive web-based management interface alongside hardware-level dip switches for instant field setup:
Hardware Mode Selection: Adjust the physical DIP switches on the base of the unit to toggle between “Pass-Through/Converter” mode or “Managed Switch/Bridge” mode based on your network architecture.
Web Interface Access: Connect a laptop to LAN Port 1, configure the laptop’s network adapter to the default subnet (1192.168.1.x), and access the web management console via the default IP address specified on the device label.
Network Configuration: Define static IP assignments, set up Virtual LANs (VLAN tags) for data segregation, and enable Quality of Service (QoS) prioritize mission-critical data streams.
System Diagnostics: Navigate to the status tab to verify link speeds, optical signal strength (DOM status), and data packet error rates. Save configuration changes and restart the unit to initialize settings.
