UNITEK USB 3.2 Gen2 M.2 SSD Enclosure Series Data Sheet
The UNITEK SolidForce series offers high-performance storage expansion for M.2 NVMe and SATA SSDs. Utilizing the USB 3.2 Gen2 standard, these enclosures provide 10Gbps bandwidth, making them ideal for high-speed data backup, 4K video editing, and portable gaming libraries.
Technical Specifications and Variants
Available through SKYRS in Pakistan, the UNITEK M.2 lineup includes specialized models for single drives, dual-bay RAID, and even MagSafe-compatible mobile storage:
| Feature |
NVMe/SATA Enclosure (S1229) |
SolidForce RAID (S1222) |
Magnetic 2230 (S1253) |
| Interface |
USB 3.2 Gen2 (10Gbps) |
USB 3.2 Gen2 (10Gbps) |
USB 3.2 Gen2 (10Gbps) |
| Protocol Support |
PCIe NVMe & SATA |
Dual PCIe NVMe / SATA |
PCIe NVMe (2230 only) |
| SSD Compatibility |
2242/2260/2280 |
2242/2260/2280 |
2230 (Ultra Compact) |
| Cooling |
Aluminum + Thermal Pads |
Active Fan + Aluminum |
Aluminum Heat Sink |
| Max Capacity |
Up to 8TB |
Up to 16TB (Dual 8TB) |
Up to 2TB |
| Special Feature |
Tool-Free / Dual Protocol |
Offline Clone / RAID 0,1 |
MagSafe / iPhone 15/16/17 |
| Connector |
USB-C (C-to-C/A Cable) |
USB-C (12V Power incl.) |
USB-C (Magnetic) |
Key Performance Features
-
10Gbps Blazing Speeds: Transfer a 10GB file in roughly 10 seconds (with NVMe SSDs).
-
UASP & TRIM Support: Enhanced data transfer protocols that reduce CPU overhead and extend SSD lifespan.
-
Smart Sleep Mode: Automatically enters sleep mode after 10–30 minutes of inactivity to save power and reduce heat.
-
Broad OS Support: Native plug-and-play compatibility with Windows 11/10, macOS, Linux, and Android.
Deployment and Installation Guide
Hardware Assembly
-
Tool-Free Entry: Most UNITEK M.2 models feature a slide-to-open or button-release mechanism.
-
SSD Placement: Insert your M.2 SSD into the internal slot at a 30-degree angle and press down.
-
Thermal Management: Apply the included silicone thermal pad directly onto the SSD chips. Place the aluminum heat exchanger/cover on top to ensure direct contact with the outer shell.
-
Securing: Use the rubber standoff or included screws to lock the SSD in place.
Installation Steps
-
Connect the USB-C cable to the enclosure and the host computer (use a USB 3.2 Gen2 port for maximum speed).
-
For RAID models (S1222), connect the external 12V power adapter if using high-consumption drives or performing offline clones.
Configuration and Performance Tuning
To verify your high-speed setup:
-
Format for Compatibility: Use Disk Management (Windows) or Disk Utility (Mac) to initialize the drive. Use exFAT if you need to move data between Windows, Mac, and Android/iPhone.
-
Offline Cloning (RAID Model): To clone a drive without a PC, insert the Source and Target drives, set the switch to “Clone,” and hold the “Start” button. LED indicators will show progress (25%, 50%, 75%, 100%).
-
iPhone Video Recording: Connect the Magnetic 2230 variant to an iPhone 15 Pro or later to record ProRes 4K/60fps video directly to external storage.
Availability and Support at SKYRS Pakistan
The UNITEK USB 3.2 Gen2 M.2 series is available exclusively at SKYRS, the authorized provider for advanced storage solutions in Pakistan.
-
Verified Genuine Stock: Access the latest UNITEK SolidForce variants with authentic internal bridge chipsets.
-
Project Solutions: SKYRS offers bulk deployment for IT departments and creative agencies across Karachi, Lahore, and Islamabad.
-
Technical Consultancy: Assistance with RAID configuration and drive compatibility is provided by the SKYRS support team.
