UNITEK 1-in-16 HDMI Splitter 4K Price in Pakistan | skyrs.com.pk

High-Performance Signal Distribution for Professional AV Environments

The UNITEK 1×16 HDMI Splitter series is engineered to take a single HDMI source—such as a satellite receiver, media player, or PC—and distribute it to 16 identical displays simultaneously. This industrial-grade solution ensures signal integrity over long distances, making it ideal for large-scale retail, control centers, and hospitality venues.

Core Technical Specifications

These specifications apply across the primary variants available for the Pakistani market:

• Input Port: 1 x HDMI (Female)

• Output Ports: 16 x HDMI (Female)

• Resolution Support: Up to Ultra HD 4K (3840 x 2160) @ 30Hz or 60Hz (variant dependent)

• Color Depth: Supports 8/10/12-bit deep color

• Audio Support: DTS-HD, Dolby-TrueHD, DTS, Dolby-AC3, and DSD

• Bandwidth: Up to 10.2Gbps – 18Gbps

• Distance: Internal signal amplification allows for input up to 15m and output up to 20m (using standard AWG26 HDMI cables)

• Power Supply: DC 12V/2A – 5V/3A (External adapter included)

Deployment and Installation

The UNITEK 1 in 16 splitter is designed for “Plug-and-Play” deployment, requiring no specialized software.

1. Physical Mounting The unit features a durable metal housing that aids in heat dissipation. It can be placed on a flat surface or mounted within a standard AV rack using the included brackets.

2. Hardware Connection

• Source: Connect the HDMI source to the “Input” port using a high-quality HDMI cable.

• Displays: Connect up to 16 monitors or projectors to the “Output” ports.

• Power: Connect the provided power adapter to a grounded outlet.

3. Cascading (Optional) For larger deployments requiring more than 16 screens, these units support multi-layer cascading. By connecting one output of the first splitter to the input of a second, the display count can be scaled significantly without losing signal quality.

Configuration and EDID Management

To ensure compatibility across different brands of monitors (e.g., mixing Samsung and Sony displays), the UNITEK units feature EDID (Extended Display Identification Data) management:

• Auto-Sensing: The splitter automatically negotiates the highest common resolution supported by all connected displays.

• Signal Reset: A dedicated reset button on the front panel allows for quick synchronization if a display is hot-swapped or if the signal is lost during a power surge.

Exclusive Availability at SKYRS Pakistan

SKYRS is the premier provider for UNITEK AV solutions in Pakistan. This specific 1 in 16 configuration, including both the Standard 1080p and the Pro 4K variants, is available exclusively through the SKYRS distribution network.

Why choose SKYRS for your deployment?

• Authenticity: Guaranteed genuine UNITEK hardware with full manufacturer warranty support within Pakistan.

• Expert Consultation: SKYRS provides localized technical support to assist with cable length calculations and signal booster requirements for complex layouts.

• Ready Stock: Immediate availability for large-scale projects, avoiding lengthy international shipping lead times.

Note: For optimal performance at 4K resolutions, SKYRS recommends the use of UNITEK Fiber Optic HDMI cables for any runs exceeding 20 meters.
