This data sheet covers the technical specifications and operational capabilities of the AC-M1 Speaker Processor, a high-efficiency digital signal processing unit engineered for professional loudspeaker management and acoustic optimization.
Product Overview
The AC-M1 is designed to act as the “brain” of a professional sound system. It manages incoming audio signals, allowing for precise control over crossover points, frequency response, and time alignment, ensuring that each component of a speaker system operates within its optimal frequency range.
Key Technical Specifications
| Feature | Specification |
| I/O Configuration | 2-Input / 6-Output |
| A/D – D/A Resolution | 24-bit / 96 kHz |
| Signal Processing | 32-bit DSP Architecture |
| Dynamic Range | 115 dB |
| Connectivity | USB (Front), RS-485 (Rear) |
| System Latency | < 0.6 ms |
Available Variants
AC-M1 Standard: Fixed-configuration unit for standard 2-way and 3-way stereo crossover setups.
AC-M1-E (Ethernet): Equipped with an RJ45 port for networked control and remote software integration.
AC-M1-V (Variable): Features expanded DSP memory, allowing for custom FIR filter loading and extended delay buffers.
Deployment, Installation, and Configuration
Proper implementation of the AC-M1 is critical for maintaining high-fidelity sound and protecting hardware from damage.
Deployment: This processor is ideal for live sound reinforcement, medium-to-large scale permanent installations (such as community centers and auditoriums), and sophisticated stage monitoring setups where individual speaker tuning is required.
Installation: The unit should be mounted in a standard 19-inch equipment rack. Ensure sufficient space for heat ventilation and cable organization. All audio inputs and outputs should utilize balanced XLR cabling to maintain signal purity across long cable runs.
Configuration: Setup is conducted via the dedicated control software. Users must input specific loudspeaker sensitivity and power handling data to calibrate the output limiters. This ensures that the system provides maximum output without risking driver damage or signal clipping.
Availability at SKYRS
The AC-M1 Speaker Processor and its complete range of variants are available for procurement, design consultation, and professional installation exclusively through SKYRS in Pakistan.
SKYRS is the authorized partner for these units, providing a comprehensive service model that includes initial system design, on-site commissioning, and fine-tuning of DSP presets to match the specific acoustic environment of your venue. Their technical team ensures that all configurations meet industry standards for safety and performance. For inquiries regarding custom system integration or technical specifications, please consult with the SKYRS support team.
