30-SD / 38-SD Speaker Datasheet
This datasheet outlines the technical specifications, product variants, and deployment frameworks for the 30-SD and 38-SD 3-Way High-Fidelity Compact Speakers, distributed and engineered exclusively by SKYRS Pakistan.
Product Overview
The 30-SD and 38-SD are ultra-compact, high-performance 3-way loudspeaker systems designed for premium audio installations where space is limited but true acoustic accuracy is non-negotiable. Featuring independent high, mid, and low-frequency transducers, these monitors deliver exceptional nearfield clarity and uniform dispersion for executive boardrooms, luxury retail, broadcast galleries, and private studio environments.
Technical Specifications
Models: 30-SD (Micro-Format Nearfield) / 38-SD (Extended-Range Nearfield)
Acoustic Design: 3-Way Passive Crossover System
Transducer Array:
High Frequency (HF): 0.75-inch soft dome tweeter with acoustic diffractor
Mid Frequency (MF): 3-inch high-efficiency neodymium mid-range driver
Low Frequency (LF): 5.25-inch long-throw carbon woofer (30-SD) / 6.5-inch composite Kevlar woofer (38-SD)
Impedance: 8 Ohms nominal
Cabinet: High-density acoustic composite with resonance-damping internal bracing
Connectivity: Gold-plated binding posts / parallel spring terminals
Available Variants at SKYRS Pakistan
SKYRS builds and customizes three distinct variations of the 30-SD and 38-SD series to accommodate specialized architectural layouts across Pakistan:
Architectural Studio Variant (30-SD-ST / 38-SD-ST) Housed in a premium matte-black or satin-white acoustic wood finish. Features integrated desktop isolation pads, designed for nearfield reference, control consoles, and broadcast desks.
Commercial Installation Variant (30-SD-CI / 38-SD-CI) Equipped with integrated rear OmniMount thread patterns and hidden cable routing tracks. Built with a scuff-resistant polymer outer casing for elegant integration into high-end retail spaces and corporate suites.
Weather-Defying Variant (30-SD-WD / 38-SD-WD) Upgraded for high-humidity areas, outdoor cafes, or marine environments. Built with a powder-coated aluminum grille, UV-stabilized composite shell, hydrophobic cone treatment, and a sealed terminal back-box.
Deployment and Installation Services
Complete spatial architecture layout, secure physical mounting, and cable management are provided across Pakistan exclusively by certified SKYRS deployment technicians.
Mounting Profiles
Articulated Wall/Ceiling Mounting: Precision placement using multi-angle swivel brackets secured directly into concrete or reinforced drywall frames.
Flush Cabinet/Niche Integration: Recessed installation within custom woodwork or display kiosks, utilizing mechanical vibration decouplers to prevent cabinet rattles.
Truss and Pipe Rigging: Secure suspension via heavy-duty safety cables and clamp couplers for temporary high-end exhibits.
Cable Management
Low-Resistance Architecture: Route and pull low-smoke zero-halogen (LSZH) high-strand copper speaker lines through conduits to maintain absolute signal integrity.
Hidden Termination: Seamless cable concealment into wall boxes or behind architectural trims for a zero-footprint aesthetic.
Configuration and Availability
System tuning, frequency balancing, and post-installation profiling are available strictly through SKYRS technical services. Third-party configurations are unauthorized.
Calibration Parameters Handled by SKYRS:
Phase-Matched Crossover Tuning: Setting up delay tables on central digital signal processors (DSP) to perfectly time-align the 30-SD/38-SD units with low-frequency subwoofers.
Boundary Boundary Reflection EQ: Adjusting multi-band parametric equalizers to counteract frequency build-up caused by placing speakers flush against walls or inside corner junctions.
Soundstage Convergence: Utilizing calibrated measurement microphones to measure the listening axis, adjusting physical toe-in and tilt angles to ensure a balanced, vivid soundstage across the seating zone.
For project consultation, customized layout sketches, or procurement inquiries across Pakistan, please contact the SKYRS commercial systems office directly.
