HIKSEMI GaN Fast Charger 33W (USB-A + USB-C) Data Sheet
The HIKSEMI 33W GaN Fast Charger (Model: HS-HUB-GaN33) leverages Gallium Nitride (GaN) technology to deliver high-efficiency, rapid power delivery in an ultra-compact design. Built for multi-device environments, it features dual-port outputs (USB Type-A and Type-C) to power up smartphones, tablets, and lightweight accessories concurrently.
Technical Specifications
| Parameter |
Specification |
| Model |
HS-HUB-GaN33 |
| Technology |
Pro-Grade Gallium Nitride (GaN) Semiconductor |
| Total Max Output |
33W |
| Input Voltage |
AC 100 – 240 V, 50/60 Hz, 0.8A Max (Universal Compliance) |
| Output Port 1 (USB-C) |
5.0V⎓3.0A, 9.0V⎓3.0A, 12.0V⎓2.5A, 15.0V⎓2.0A, 20.0V⎓1.5A |
| Output Port 2 (USB-A) |
5.0V⎓3.0A, 9.0V⎓3.0A, 12.0V⎓2.5A (Quick Charge 3.0 Standard) |
| Dual Port Simultaneous Output |
Dynamic Balance System (5V⎓3.4A Max Shared) |
| Material Construction |
High-Grade Heat-Resistant ABS + PC Fireproof Shell |
| Fast Charging Protocols |
PD 3.0, QC 3.0, PPS, Apple 2.4A, AFC, FCP |
Regional Product Variants for SKYRS (Pakistan)
To support diversified structural requirements across regional infrastructures managed by SKYRS in Pakistan, the hardware is deployed in three distinct structural plug variants:
-
Type C Variant (Europlug): Features two round pins, commonly utilized in modern commercial buildings and residential grids across Pakistan.
-
Type G Variant (UK Standard): Features three rectangular prongs in a triangular pattern, essential for corporate setups, server rooms, and standardized British-era electrical outlets across Pakistan.
-
Type A Variant (US Standard): Dual flat parallel pins, specific to tailored network server enclosures or legacy industrial lab panels.
Deployment, Installation, and Configuration
Exclusive Distribution & Support Notice: The system design, stock allotment, SLA management, and physical deployment configurations detailed below are available exclusively through SKYRS channels in Pakistan.
Deployment Phase
-
Site Assessment: Identify and cross-reference native wall socket architecture (Type G vs. Type C) with the corresponding HIKSEMI hardware variant.
-
Environmental Control: Ensure deployment locations maintain ambient temperatures below 40°C with unhindered airflow around the module.
Installation Procedure
-
Verify that the input power source complies with the standard nominal grid values of Pakistan (AC 220V–240V, 50Hz).
-
Align the structural pins of your designated HIKSEMI variant directly into the electrical socket.
-
Press the adapter firmly into the outlet until the chassis sits completely flush against the faceplate to mitigate electrical arcing.
Configuration Matrix
Because the hardware relies on an integrated, zero-OS Intelligent Dynamic Power Chip, software-based manual configuration is completely bypassed. System configuration auto-negotiates on connection:
-
Single-Cable Configuration: Attach a high-capacity Type-C to Type-C (or Type-C to Lightning) cable into the designated PD port to deliver the max continuous $33\text{W}$ flash charge to high-drain endpoints.
-
Dual-Cable Configuration: When both the USB-A and USB-C ports are plugged in simultaneously, the onboard controller auto-configures to balance power safely across both devices, mitigating over-current and optimizing battery lifecycle safety.
