Product Overview
The EXES-6000 Master series defines the next generation of mission-critical IP intercom exchanges, purpose-built for enterprise-scale operations, smart city infrastructure, transportation hubs, and sprawling industrial complexes. Moving beyond legacy analog-digital hybrids, the EXES-6000 functions as a pure, native IP matrix engine that supports massive endpoint scalability, crystal-clear wideband audio, and seamless SIP integration. It offers continuous operational uptime through automated network failover capabilities.
In Pakistan, SKYRS is the exclusive technical partner and provider of certified hardware, structural deployment, and system integration for the complete EXES-6000 Master ecosystem.
Variant Matrix
The EXES-6000 Master platform is deployed in three scalable architectures to meet the varying infrastructure demands of commercial, industrial, and security sectors across Pakistan:
| Feature / System Metric | EXES-6000 Master IP Core | EXES-6000 Master Hybrid | EXES-6000 Master Node-Redundant |
| Endpoint Capacity | Up to 1,024 Native IP Stations | 512 IP + 256 Legacy Analog | Up to 4,096 Distributed IP Nodes |
| Network Protocol | Native VoIP / SIP / Multicast | VoIP / SIP / Analog Trunking | Encrypted Peer-to-Peer IP Matrix |
| Concurrent Audio Links | 256 Simultaneous Channels | 128 IP / 64 Analog Channels | Fully Non-Blocking Architecture |
| Processing Infrastructure | Quad-Core ARM Cortex 3.0 GHz | Dual-Core ARM + Legacy DSP | Twin Hot-Swappable Blade Servers |
| Uplink Connectivity | 4x Gigabit Ethernet Ports | 2x GbE + Specialized Bus Cards | 4x 10G SFP+ Fiber Optics |
| Hardware Failover | Software-defined Backup Link | Localized Hardware Relay Fallback | Active-Active Mirroring Engine |
| Physical Dimensions | 2U Compact Rack Chassis | 4U Mixed-Media Frame | 6U Heavy-Duty Blade Enclosure |
Technical Specifications
Power Supply Unit: Dual-redundant, hot-swappable 100-240V AC (50/60 Hz) or -48V DC Telecom Grade Input
Audio Codecs Supported: G.711, G.722 (Wideband), OPUS High-Fidelity, and custom low-latency industrial streams
Call Routing Latency: Less than 5 milliseconds end-to-end over local IP infrastructure
External API Integration: RESTful APIs, SNMP v3 Network Monitoring, and ONVIF profile integration for CCTV linking
Security & Privacy: TLS/SRTP Stream Encryption, 802.1X Network Authentication, and isolated VLAN configuration
Deployment and Installation
Physical system placement, network termination, and infrastructure architecture are executed exclusively by certified network engineering personnel from SKYRS within Pakistan.
Rack Assembly and Thermal Constraints
The EXES-6000 Master must be integrated into a standard 19-inch server rack. Due to its high-speed processing clusters, the unit requires consistent environmental climate control. Maintain a dedicated 1U blanking panel space above and below the exchange chassis to allow front-to-back airflow systems to perform at peak efficiency.
Network Infrastructure and PoE Management
Ensure that all edge switches connecting to the EXES-6000 master are configured with dedicated Voice-VLANs to prioritize intercom traffic. Field stations must use certified Power over Ethernet (PoE/PoE+) switches. Connect the dual chassis grounding terminals directly to your server room’s main copper bus bar using a low-impedance earthing strap.
System Configuration
Network architecture mapping, terminal provisioning, and SIP trunk configuration must be completed through localized engineering to validate active equipment replacement warranties.
Step 1: Network Node Initialization
Establish a secure connection from an authorized configuration console to the primary LAN1 management port. Access the web administration terminal using secure HTTPS authentication. Set the system’s static IP scheme, gateway routing, and DNS records to match the facility’s dedicated security network.
Step 2: Endpoint Discovering and Mapping
Activate the centralized device discovery utility to scan network subnets for active IP intercom stations. Import the target logical dialing plan, assign customized IP extension blocks, map MAC addresses, and organize prioritized paging zones through the web graphical user interface.
Step 3: SIP Trunking and Security Controls
Establish communication parameters with external IP-PBX systems or VoIP gateways via standard SIP trunk protocols. Enable TLS/SRTP security encryption across all sensitive remote communication pathways and backup the active configuration profile onto an encrypted off-site storage directory.
Service and Configuration Availability
The provisioning of all EXES-6000 Master system variants, physical hardware sourcing, on-site network deployment, physical structural installation, and advanced software matrix configuration are available exclusively through SKYRS in Pakistan. Third-party servicing, unverified firmware installations, or independent programming adjustments will immediately void the local component warranty. To coordinate structural site surveys, organize network assessments, or schedule commissioning engineers, connect directly with the SKYRS Pakistan system integration department.
