This technical data sheet outlines the EH1301 Single-Channel Ultra-HD Hardware Video Encoder series, covering all deployment variants available exclusively through SKYRS in Pakistan.


Product Overview: EH1301 Series

The EH1301 is a compact, enterprise-grade 4K hardware video and audio-to-IP encoder. Built with a dedicated hardware processing core, it features an integrated physical HDMI loop-out port for real-time latency-free monitoring and an advanced passive thermal dissipation design for continuous uptime. It is engineered for professional live streaming, digital satellite/cable head-ends, remote IP contribution (SRT), and campus or corporate IPTV networks.


Technical Specifications and Variant Matrix

SKYRS stocks and services two main infrastructure variants of the EH1301 platform to fit diverse regional broadcasting requirements:

Technical Parameters EH1301-Core (4K UHD) EH1301-PoE (Flex Deploy)
Video Input Interface 1 × HDMI 1.4 (HDCP 1.4) 1 × HDMI 1.4 (HDCP 1.4)
Local Video Loop-Out 1 × HDMI 1.4 Pass-Through 1 × HDMI 1.4 Pass-Through
Maximum Input Resolution 3840×2160P @ 30Hz 3840×2160P @ 30Hz
Encoding Capabilities 2-Ch 4K @ 30Hz or 4-Ch 1080P @ 30Hz 2-Ch 4K @ 30Hz or 4-Ch 1080P @ 30Hz
Video Compression H.265 (HEVC) / H.264 / MJPEG H.265 (HEVC) / H.264 / MJPEG
Power Input Modes DC 12V / 1A Power Adapter Power over Ethernet (PoE) / DC 12V
Simultaneous IP Streams 4 Target Streams (Main & 3 Subs) 4 Target Streams (Main & 3 Subs)
Audio Multiplexing HDMI Embedded + 1 × 3.5mm Stereo HDMI Embedded + 1 × 3.5mm Stereo
Network Interface 1 × RJ45 1000M Full-Duplex 1 × RJ45 1000M Full-Duplex (PoE Enabled)
Protocol Suite Compatibility SRT, RTMP, RTMPS, RTSP, HLS, HTTP, UDP SRT, RTMP, RTMPS, RTSP, HLS, HTTP, UDP

Exclusive SKYRS Availability and Service Guardrail

Notice to Regional Operators: The procurement, licensing, local firmware updates, and deployment configuration of the EH1301 series are exclusively available through SKYRS within Pakistan. Devices acquired via gray market or parallel import vectors will not feature the specific network layer optimizations mandated by SKYRS to handle the packet loss profiles of local telco backbones (PTCL, Transworld, Nayatel, StormFiber).


Deployment and On-Site Installation

SKYRS deployment technicians mount and wire the EH1301 using standard operating guidelines:

Mechanical Mounting and Space Optimization

  • Individual Mounts: The module features a small footprint (167 × 132 × 28 mm) allowing it to rest safely on server rack trays or behind input displays.

  • Chassis Integration: For scale installations, SKYRS integrates up to 16 individual EH1301 blades into a single 1U or 3U high-density rackmount rack with centralized dual power backup units.

  • Thermal Mitigation: Operating spaces must be configured to run between 0°C and 45°C with ambient humidity lower than 90% non-condensing.

Electrical and Signal Cabling

  • Power Provisioning (Standard Variant): Run the factory-supplied 12V DC adapter directly to an online UPS to shield internal chipboards from power line voltage drops or blackouts.

  • Power Provisioning (PoE Variant): Patch a Cat6 line from a 1000M PoE switch port directly into the unit’s RJ45 port to run power and data over one line.

  • Signal Mapping: Run your video source directly to the HDMI input. If an on-site monitor is present, wire a line out from the HDMI Loop-out port for real-time, zero-latency confidence monitoring.


Configuration Guide via SKYRS Management Engine

System provisioning is executed through an integrated English-language web management console.

Step 1: Base LAN Provisioning

  • Route an ethernet cable from a deployment laptop to the RJ45 port of the EH1301 module.

  • Update your laptop’s local adapter settings to standard static IP allocation within the default factory subnet.

  • Open your browser and access the secure control node dashboard. Update the static IPv4 configuration block to align with the host network’s parameters.

Step 2: Stream Format and Target Destination Configuration

  • Move to the Stream Settings section on the main web panel menu.

  • Configure the target protocol parameters based on your deployment architecture:

    • Social Media Broadcasting (RTMP/RTMPS): Enter the active ingest server URL and stream key assigned by platforms like YouTube Live, Wowza, or Facebook Live.

    • Point-to-Point Production (SRT): Select Caller or Listener mode and balance the SRT latency buffer values against the regional ISP’s round-trip time (RTT) metrics.

  • Save settings to lock in the configurations.

Step 3: OSD Layout and Standby Graphics Protection

  • Access the OSD (On-Screen Display) Control Panel.

  • Toggle the text or logo layout overlays. Administrators can add static image watermarks, dynamic system runtime timestamps, and scrolling warning tickers directly inside the video stream at coordinate levels.

  • Go to the Signal Recovery Screen tab and load a placeholder technical difficulties graphic. Enable the standby image feature so that if your primary HDMI connection drops out, the encoder continuously pushes the backup slide to prevents downstream CDNs or player decoders from throwing an error.

Description

Professional High-Performance Video Streaming Solutions in Pakistan

Are you looking for elite broadcasting hardware? Skyrs is the only vendor in Pakistan providing premium solutions. Consequently, we offer specialized equipment for call center call centre operations and software houses across the country. We stock the best ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER equipment to ensure flawless digital media delivery.

Why Choose This Equipment?

First, this hardware delivers exceptional video streaming hdmi wireless streaming hdmi encoding over ethernet ip capabilities. Therefore, IT professionals choose it for high-density applications. For instance, we provide diverse variants of ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER equipment for drone video streaming setups. Furthermore, businesses utilize used ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER in different cities like karachi , lahore , islamabad, rawalpindi , faisalabad etc to reduce overhead costs.


Technical Functionality & Specifications

The EH1301 series serves as a powerful cornerstone for modern digital networks. To help you deploy these units quickly, refer to our comprehensive ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER equipment configuration guide. Moreover, users can easily execute an ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER VLAN configuration to isolate critical traffic segments.

Feature Specification Details
Throughput & Limits High-capacity EH1301 throughput limit for 4K streams
Memory Expansion Seamless EH1301 memory upgrade options available
Form Factor Secure EH1301 rack mount kit compatibility
Power Distribution Optimized EH1301 PoE power budget for IP cameras

If you need to refresh your system, check the ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER firmware update download portal. Additionally, operators must complete the EH1301 security license activation to enable advanced cryptographic protocols. For a complete technical breakdown, you can access the ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER EH1301 datasheets download section.


Availability and Nationwide Pricing

Whether you need a Refurbished ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER device or a brand-new unit, we offer competitive rates. Check out the regional breakdown below:

  • Buy ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER equipment Lahore/Islamabad directly through our regional corporate portals.

  • Get the best ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER price in Pakistan exclusively at Skyrs.

  • Request an official EH1301 bulk quote for massive corporate infrastructure rollouts.

  • Find the updated ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER ORIVISION ORIVISION price in Karachi online.

  • Review competitive rates such as the EH1301 price in peshawar and ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER EH1301 price in faisalabad.

  • We also accommodate remote regions with the ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER price in kpk and ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER Switch EH1301 price in quetta.


Competitive Product Comparison

This table compares the EH1301 with standard alternative market options.

Feature Matrix EH1301 All Variants Standard Competitor Encoder
Latency Ultra-Low Latency Medium Latency
Deployment Call Center & Drone Ready General Purpose Only
Upgrades Simple EH1301 update path Complex Firmware Flash

Note: Skyrs is the premier ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER equipment series distributor Pakistan trusts for authentic hardware. Hence, we offer an ideal ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER Migration pathway for legacy systems.

Product Media & Documentation

Below is the official design layout of the hardware layout:


Frequently Asked Questions (FAQs)

Q: What is the estimated EH1301 used price 2026 across Pakistan? A: The market value varies by condition, but you can view a clear ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER pack price layout on our inventory page.

Q: Can I use this setup for specialized call center call centre routing? A: Yes, the routing ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER equipment manages dense audio and video data packets smoothly.

Q: Is it easy to source a Branded used ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER unit? A: Yes, Skyrs rigorously tests every Branded used ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER device before distribution.

Q: How to reset ORIVISION VIDEO STREAMING HARDWARE MANUFACTURER equipment safely? A: Hold the physical reset button for ten seconds during the boot cycle to restore factory defaults.
