CZI TK4 Tethered Power System Data Sheet for SKYRS
Product Overview
The CZI TK4 Tethered Power System is an advanced ground-to-air high-voltage power and communication platform engineered for continuous, 24-hour drone operations. Utilizing an 800V high-voltage direct current transmission architecture, it drastically minimizes line loss and cable heating, delivering uninterrupted power and high-speed data transmission for extended enterprise drone missions.
Core Technical Specifications
Ground Station Input: 176–264 VAC, 50/60 Hz
High-Voltage Transmission: 800V DC power transmission via high-performance tether cable
Airborne Output: Rated 4 kW output at 50 V DC
Tether Cable Length: 110-meter standard configuration; optional 200-meter configuration available
Data Communication: 100 Mbps Power-Line Communication (PLC) supporting real-time HDMI and Ethernet video output
Ground Station Weight: $\le 13\text{ kg}$ (including standard 110m tether and integrated cable management)
Airborne Module Dimensions & Weight: $\le 190 \times 155 \times 86\text{ mm}$; $\le 2\text{ kg}$ (excluding connectors)
Safety Features: Included grounding rod to safely discharge induced voltages, integrated backup battery for safe emergency descent, and smart display monitoring
Operating Temperature: $-20^\circ\text{C}$ to $+50^\circ\text{C}$
Available CZI TK4 Variants for SKYRS
TK4 Standard Enterprise Variant: Optimized for heavy-duty industrial drone platforms, delivering stable high-voltage power and 100 Mbps data integration for persistent aerial monitoring.
TK4 High-Power Lighting & Payload Bundle Variant: Configured to simultaneously support heavy illumination packages—such as an 800W ML200 matrix light and a 300W GL300 spotlight—for large-scale emergency response and continuous night operations.
TK4 Extended Altitude Variant: Equipped with a specialized 200-meter high-strength tether configuration for elevated surveillance and infrastructure inspection requirements.
Deployment, Installation, and Configuration Availability
Professional deployment, technical installation, and complete system configuration for the CZI TK4 Tethered Power System and all associated variants are available exclusively at SKYRS in Pakistan. Expert engineering support ensures proper electrical grounding, power calibration, and hardware integration for critical security, public safety, and industrial applications. Contact SKYRS for authorized system packages, technical service, and custom deployment solutions.
Modern enterprise sectors, security agencies, and emergency response teams across Karachi, Lahore, Islamabad, Rawalpindi, Faisalabad, Quetta, Peshawar, Multan, Hyderabad, and Sialkot demand dependable aerial technology. From corporate offices, industrial plants, hospitals, and residential smart homes to remote fuel pump stations and energy installations, deploying high-performance unmanned payloads ensures reliable oversight. Organizations looking for cutting-edge drone hardware can review manufacturer specifications directly via CZI Official Website and acquire compatible units locally through Skyrs IT Hardware & Electronics Retailer.
Advanced CZI enterprise accessories transform how ground crews manage critical inspections, crowd control operations, and emergency relief missions. High-output optical searchlights like the CZI GL60 Plus, GL300, and GL10 provide intense illumination for police patrols and nighttime monitoring. Meanwhile, long-range acoustic devices like the MP130 V2 and MP140 megaphone payloads deliver clear voice broadcasting across vast operational areas. Furthermore, multi-functional accessories like the LP12 spotlight loudspeaker combo and drop-release mechanisms such as the TH4 and TH6 facilitate precision supply drops for remote rescue tasks.
The CZI TK4 Tethered Power System stands apart from standard battery-operated drone lights by offering continuous ground-powered illumination through an advanced tether architecture. While typical competitor drone lights suffer from severe flight-time limitations of 20 to 30 minutes, the TK4 series provides uninterrupted multi-hour operation. Delivering extreme luminous flux and stable overhead monitoring, it outperforms portable balloon lights and conventional mobile generators during rapid disaster response across Pakistan.
Yes, CZI payloads integrate seamlessly via the DJI PSDK interface, allowing direct control through DJI Pilot 2 software.
Units like the LP12 and GL60 series offer versatile mounting brackets compatible with both DJI Matrice 350 RTK and Matrice 30 series aircraft.
Operating high-power searchlights at maximum output draws significant energy from the drone battery, reducing overall flight time by approximately 15 to 25 percent depending on the model.
The CZI TH4 supports multi-payload drop capabilities for emergency relief, while heavy-lift variants like the TH6 manage substantial cargo weights for delivery platforms.
