CZI TK3 Tethered High-Power System Data Sheet for SKYRS
Product Overview
The CZI TK3 Tethered High-Power System (frequently referenced as the TK3 series) is an advanced ground-to-air power supply platform engineered to eliminate battery limitations for enterprise drones. By converting standard AC utility power into high-voltage DC, it delivers continuous, uninterrupted energy through a specialized ultralight tether cable, enabling 24-hour flight endurance for prolonged security, emergency response, and aerial monitoring.
Core Technical Specifications
Ground Station Input Voltage: 90–264 VAC (Supports 50/60 Hz utility power, generators, or mobile energy packs)
High-Voltage DC Output: $\ge 400\text{ VDC}$
Power Output Capacity: Up to 3,000W (at 176–264V AC input); Up to 1,500W (at 90–175V AC input)
Power Transmission Cable: 80-meter high-strength nickel-alloy tether cable (diameter $<2.8\text{ mm}$, weight $12\text{ g/m}$, tensile strength $>200\text{ N}$)
Ground Terminal Weight: Compact backpack-portable design at approximately $7.5\text{ kg}$
Airborne Module Weight: ~320g for DJI M30 series; ~566g for DJI Matrice 350 RTK / 300 RTK
Safety Features: Intelligent 5-inch real-time data display (showing output power, cable tension, temperature protection, and fault alerts), plus integrated backup battery support for safe emergency descent.
Available CZI TK3 Variants for SKYRS
TK3 Standard Enterprise Variant: Optimized for standard multi-payload operations, providing versatile high-voltage distribution across compatible industrial drone airframes.
TK3 Matrix Light & Spotlight Bundle Variant: Configured directly to drive heavy-load illumination accessories—such as the CZI ML200 or high-output gimbal searchlights—for continuous night-time disaster recovery and perimeter defense.
TK3 Specialized Air-Module Bundles: Tailored configurations featuring dedicated sky-end modules matching either the DJI Matrice 30 series or the Matrice 350/300 RTK platforms.
Deployment, Installation, and Configuration Availability
Professional deployment, technical installation, and complete system configuration for the CZI TK3 Tethered High-Power System and its associated variants are available exclusively at SKYRS in Pakistan. Expert engineering support ensures correct power calibration, hardware integration, and operational readiness for critical infrastructure protection and emergency management sectors. Contact SKYRS for authorized system packages, maintenance, and technical services.
