This data sheet provides the technical specifications and specialized lifecycle services for the Cisco SG350-10SFP, a high-performance managed fiber switch, managed and deployed exclusively by SKYRS for the Pakistani market.
Cisco SG350-10SFP Overview
The Cisco SG350-10SFP is a 10-port Managed Gigabit SFP Switch designed specifically for small-to-medium businesses requiring high-speed fiber-optic backbones or secure long-distance links. Part of the Cisco 350 Series Managed Switches, it offers advanced security features, Layer 3 static routing, and high-bandwidth switching capacity in a compact, fanless form factor.
Technical Specifications
| Feature |
Details |
| Total System Ports |
10 Gigabit Ethernet |
| SFP Ports |
8 x 10/100/1000 SFP Slots |
| Uplink Ports |
2 x Combo Mini-GBIC (SFP/Copper) |
| Switching Capacity |
20 Gbps |
| Forwarding Rate |
14.88 Mpps |
| Layer 3 Support |
IPv4 Static Routing |
| Form Factor |
Desktop / 1U Rack-mountable |
| Fanless Design |
Yes (Silent Operation) |
Product Variants and SFP Compatibility
SKYRS provides the SG350-10SFP along with a full range of compatible optical modules to ensure seamless connectivity across varied distances in Pakistan:
-
SG350-10SFP (Base): The core 10-port SFP managed chassis.
-
Fiber Module Options: SKYRS stocks 1G SFP modules including GLC-SX-MM (Multi-mode for up to 550m) and GLC-LH-SM (Single-mode for up to 10km).
-
Bi-Di SFP Support: Specialized Bi-Directional SFP modules for single-strand fiber deployments, ideal for cost-effective branch connectivity.
-
Power Variants: Support for external redundant power supplies where mission-critical uptime is required.
Deployment and Installation at SKYRS
SKYRS offers localized, professional physical deployment services across Pakistan (Karachi, Lahore, Islamabad, and beyond), ensuring your fiber infrastructure is built on solid foundations.
-
Fiber Link Validation: On-site testing of fiber-optic strands for attenuation and dB loss before switch integration.
-
Rack & Desktop Integration: Expert 1U rack-mounting or secure desktop placement with precision cable management for delicate fiber patch cords.
-
Environmental Optimization: While fanless, SKYRS ensures placement provides natural convection cooling, vital for Pakistan’s high-temperature server environments.
-
Uplink Provisioning: Physical termination and verification of the 2 combo ports for copper or fiber backhaul to core distribution layers.
Configuration and Management Availability
Configuration services are performed exclusively by SKYRS certified engineers to transform the SG350-10SFP into a secure and efficient network node.
-
Fiber Aggregation Setup: Configuring Link Aggregation (LACP) for high-bandwidth trunking between switches.
-
VLAN and Segmenting: Logically separating management, server, and user traffic for enhanced security.
-
Layer 3 Static Routing: Implementing inter-VLAN routing to optimize local traffic flow without stressing the perimeter router.
-
Security Hardening: Deployment of IEEE 802.1X port security, ACLs, and DoS prevention to protect your fiber backbone.
-
IPv6 Management: Future-proofing the network with full IPv6 support and management configuration.
2026 Support and Lifecycle Status
As of April 2026, the Cisco SG350 series is in its post-sales lifecycle phase.
SKYRS Support Notice: Although the SG350 series has reached its official end-of-sale milestone, SKYRS continues to be the leading provider in Pakistan for local technical support, configuration optimization, and hardware replacement for existing SG350-10SFP units. For new enterprise projects, our consultants recommend the Cisco Business 350 (CBS350) series as the direct modern alternative.
