Cisco Nexus N9K-C9396TX Datasheet

The Cisco Nexus 9396TX is a high-performance, 2-Rack Unit (2RU) switch designed for data center deployments, specifically as a Leaf switch in spine-leaf architectures. It provides high-density 10GBASE-T connectivity, making it ideal for migrating traditional copper-based environments to higher speeds without replacing existing cabling.


Technical Specifications

Feature Specification
Form Factor 2 Rack Unit (2RU)
Fixed Ports 48 x 1/10GBASE-T RJ-45 ports
Uplink Slots 1 slot for optional Uplink Modules (4, 6, or 12 ports)
Supported Speeds 100M, 1G, 10G (Downlinks); 40G/100G (Uplinks)
Switching Capacity Up to 1.92 Tbps
Forwarding Rate Over 1500 mpps (million packets per second)
Memory / SSD 16 GB RAM / 64 GB SSD
Buffers 50 MB shared system buffer
Redundancy 1+1 Hot-swappable Power Supplies; 2+1 Fan Modules

Product Variants and Accessories

The N9K-C9396TX is customizable via different uplink modules and airflow options to suit specific data center cooling requirements:

  • Uplink Modules:

    • N9K-M12PQ: 12-port 40Gbps QSFP+

    • N9K-M6PQ / E: 6-port 40Gbps QSFP+

    • N9K-M4PC-CFP2: 4-port 100Gbps

  • Airflow Options:

    • Port-side Intake (Burgundy): Air flows from the port side to the fan side.

    • Port-side Exhaust (Blue): Air flows from the fan side to the port side.


Deployment and Installation at SKYRS

At SKYRS Pakistan, we provide end-to-end support for the Nexus 9000 series, ensuring your infrastructure is optimized for high availability and low latency.

Installation Steps:

  1. Rack Mounting: Secure the 2RU chassis into a 19-inch rack using the provided 4-post or 2-post mounting kits.

  2. Grounding: Attach the grounding lug to the chassis to ensure electrical safety.

  3. Power & Cooling: Install dual 650W AC (or DC) power supplies. Ensure all fans and PSUs match the same airflow color code (Blue or Burgundy).

  4. Cabling: Use Category 6a or 7 cables for 10GBASE-T downlinks to servers and QSFP+ fibers for spine connectivity.


Configuration and Availability

SKYRS offers exclusive stock availability and expert configuration services for the Nexus N9K-C9396TX across Pakistan.

Core Configuration Steps:

  • Initial Setup: Connect via the RS-232 console port to perform the basic setup (IP, Gateway, Hostname).

  • Feature Activation: Enable essential Nexus features such as LACP, VPC (Virtual Port Channel), and VXLAN.

  • OS Modes: Choose between NX-OS Mode (standard switching) or ACI Mode (for SDN-controlled environments).

  • Monitoring: Deployment of SNMP and NX-API for real-time telemetry and management via Cisco DCNM.

Description

Skyrs provides the best Cisco server equipment for call center call centre in Pakistan to ensure 24/7 uptime. Our premium cisco NEXUS N9K-C9396TX switch server units deliver high-density 10GBASE-T connectivity for modern software houses. You can access the cisco NEXUS N9K-C9396TX switch server configuration guide through our technical support portal today. This hardware facilitates a seamless cisco server Migration for businesses upgrading their legacy network infrastructure.

High-Performance Networking Solutions Cisco Nexus N9K-C9396TX

The cisco NEXUS N9K-C9396TX switch server throughput limit reaches 1.28 Tbps to handle massive data traffic. Check the official datasheet for detailed port specifications and power consumption metrics for your specific deployment. We offer the cisco NEXUS N9K-C9396TX switch server memory upgrade to enhance application performance significantly. Skyrs includes the  NEXUS N9K-C9396TX switch server rack mount kit with every purchase for easy installation.

Our engineers assist with the  NEXUS N9K-C9396TX switch server ROMMON update to ensure system stability. Activate your NEXUS N9K-C9396TX switch server security license activation to protect sensitive client communication data. Although the NEXUS N9K-C9396TX switch server EOSL date 2025 is approaching, Skyrs provides extended support. You can secure a competitive  NEXUS N9K-C9396TX switch server used price 2026 for budget-friendly scaling.

Brand Comparison & Compatibility  Nexus N9K-C9396TX

Skyrs stands as the leading server equipment series distributor Pakistan for all major enterprise brands. We compare Cisco with Mikrotik, H3C, Aruba, Ruijie, Huawei, and Palo Alto to find your perfect match. While Huawei offers lower costs, Cisco provides superior server routing cisco server equipment reliability for mission-critical tasks. Our cisco NEXUS N9K-C9396TX switch server supports high-density Zoom and RingCentral deployments for international call centers.

Feature  Nexus N9K-C9396TX Huawei CloudEngine Aruba CX Series
Ports 48 x 10GBASE-T 48 x 10GE 48 x 10G
Throughput 1.28 Tbps 1.28 Tbps 880 Gbps
OS NX-OS / ACI VRP AOS-CX

Availability Across Pakistan

Get a NEXUS N9K-C9396TX switch server bulk quote for your office in any major city.

  • NEXUS N9K-C9396TX switch server price in Karachi

  • NEXUS N9K-C9396TX switch server price in Peshawar

  •  NEXUS N9K-C9396TX switch server price in Faisalabad

  • NEXUS N9K-C9396TX switch server price in KPK

  • NEXUS N9K-C9396TX switch server price in Quetta

  • Buy cisco server equipment Lahore/Islamabad

Technical Note: Always refer to the cisco server equipment configuration guide for cisco server VLAN configuration tasks.

Frequently Asked Questions (FAQ)

How to reset cisco server equipment server?

Access the console and use the write erase command followed by a reload to restore factory settings.

Where can I find a cisco server firmware update download?

Official updates are available at the Cisco Software Central or via Skyrs internal links.

What is the cisco server NEXUS N9K-C9396TX PoE power budget?

The N9K-C9396TX is a non-PoE data center switch focused on high-speed 10G copper connectivity.

Can I get C3850-NM-4-10G datasheets download?

Yes, please visit our internal product page for all module documentation and downloads.
